KSF-5200-000
KSF portable assembly lift CM-520 - max. height 4,9m - 90kg
Order
Ordering is only possible with a professional partner login.
More details.
If you're interested in a quotation, please fill a quote basket.
More details.
If you're interested in a quotation, please fill a quote basket.
Description
- Easy to carry thanks to compact and light design
- Built-in spirit level
- Adjustable speed (230V) with remote control + lever for manual operation in case of power failure
- 4 adjustable support legs (= always work horizontally when there are differences in level)
- 1 folding support leg for working close to a wall
- Delivered with folable and removable loading platform
- Equipped with automatic brake in case of overload
- Material: aluminium
- Max. lifting height: 4.9 m
- Lifting capacity: 140 kg - 3,0 m / 130 kg - 4,0 m / 90 kg - 4,9 m
- Min. base height: 1.19 m
- Dimensions closed base: 38 x 38 cm (LxW)
- Dimensions open base: 150 x 140 cm (LxW), adjustable
- Loading platform (foldable): 75 x 45 cm
- Weight: 38 kg
- Weight of loading platform: 5 kg
- Wheels: standard
Order information
KSF portable assembly lift CM-520 - max. height 4,9m - 90kg
Article code:
KSF-5200-000
Weight (kg):
38 kg
EAN-code:
5414618944727
SKU:
10367500001
Unit:
Pc.
MOQ:
1,00 Pc.
PG:
A
Sufficient quantity on stock
No or Insufficient quantity on stock
PG = Product shipment group
